Temperature-dependent charge injection behavior of edge and top contacted memory cell. The charge injection efficiency is reflected by the threshold shift under ultrafast (10 ns) P/E operation, in which the pulse amplitude are respectively -15 V and 20 V for program and erase. Their distinct temperature dependence is indicated by the dash guidelines.
