Line Plot from Scientific Research

The new beam optics with a wedge transporting 48 mm mrad in the X plane and 100 mm mrad in the Y plane up to the wedge location. The beam envelope (Fig. 4 ) shows the beam size in 2 values and the dispersion (dashed line) along the beamline (the lower half shows the beam envelope in the X plane (bending plane) and the upper half shows the envelope in the Y plane.). The x markers show the beam size from the BDSIM simulation along the beamline. Typically, the beam shape along the beamline follows a Gaussian distribution. During the beam-optics design phase, it is common practice to use 2 ( is the standard deviation of the distribution of sizes of the beam) values to effectively represent the beam envelope.
