Line Plot from Scientific Research

The discharge power is set to 10 kW for A,B) 10 s or 50 kW for C,D) 1 s . Pack current (red) and pack voltage (blue) develop over the constant power pulse as the pack discharges. A,C) The left sides of the image shows simulation data for the beginning of life with 4 mΩ ESR and 177 F capacitance.
