Line Plot from Scientific Research

The discharge power is set to 10 kW for A,B) 10 s or 50 kW for C,D) 1 s . Pack current (red) and pack voltage (blue) develop over the constant power pulse as the pack discharges. B,D) Right side of the image shows simulation data for end-of-life with 8 mΩ ESR and 141.6 F capacitance. A pale red dotted line indicates the application voltage limit. Simulations have been carried out using Skeleton Technologies’ model for industrial Supercapacitor cells.
