LSV curves of bare TiO2anatase layers, and after Pt SAs deposition via reactive (2 mM H2PtCl6) or SEA (10 mM (NH3)4PtCl2) approach. For SEA deposition, the curve after heat treatment at 400 C in air is additionally shown.
#Line Plot#LSV Curves#TiO2 Anatase Layers#Pt SAs Deposition#H2PtCl6#(NH3)4PtCl2#SEA Approach#Heat Treatment
