Heatmap from Scientific Research

The co-evolution analysis for CsoS1A and CsoS1E. For each protein pair, the co-evolution map is shown at the top, and an atomic model is at the bottom, colored as inFigure 1. The residues with strong co-evolution correlation are indicated with a red circle and colored in red in the structural model. The co-evolution analysis for CsoS1A and CsoS1E (A), as well as CsoS4A and CsoA4B (B), strongly suggests interhomooligomer interactions. In contrast, in the case of CsoS1E and CsoS4A/B (C), intrahomooligomer interactions are likely identified. See alsoTable S2.
