Sojourn time $10^{-2}$10-2 quantiles for a range of task granularities on a hybrid Slurm/MPI/OpenMP parallel system with $p=5$p=5 MPI processes (each on a different server), $r=10$r=10 OpenMP threads per process, for a total of $w=50$w=50 workers. The tasks have exponential service times, and the task service rate is scaled to maintain a constant expected per-job workload.
#Line Plot#Error Bars#Sojourn Time#Task Granularity#Slurm#MPI#OpenMP#Parallel System#Exponential Service Times
