Scatter Plot from Scientific Research

STEM spectroscopy experiments on agglomerates from LNMO a,b) LNMS10 c,d) LNMA01 e,f) and LNMA10 g,h) For each specimen, a HAADF overview image provides a survey of the ROI using Z-contrast. Their compositional EDX maps are presented as false color density maps, grayoxygen, bluemanganese, rednickel, and greendopant (Sn/Al if present). Color composite images for the doped samples are also presented, providing a sense of the materials chemical segregation. For each sample, a histogram showing the relative Ni content for all samples is presented. For doped samples, bivariate histograms are used to relate the relative Ni content to the dopant. The point marked N represents the nominal composition for each sample.

DOI
