Pulsing stability over 1000 cycles of pristine PBTTT-8O OECTs in (from top to bottom) the full operating range, the saturation regime and the subthreshold regime (Ti/Au SD electrodes, VDS= -0.5 V, d = 45-57 nm, W = 2.7-3.1 mm, L = 2.0 mm,WdL= 68-81 nm). Inset: IDSretention after 1000 ON/OFF cycles normalized by the maximum IDSreached for all cycles.
#Line Plot#Pulsing Stability#OECTs#Operating Range#Saturation Regime#Subthreshold Regime#Electrodes#IDS Retention#ON/OFF Cycles
