Line Plot from Scientific Research

Conductance of the transistor measured before and after gate force operation, showing high- and low-resistance states. Insets display corresponding PFM phase images of the CIPS on top of the MoS 2 channel, with thick dashed lines indicating the edges of the underlying MoS 2 channel along the current flow path. The gated region is highlighted by the blue dashed box. Clear polarization switching is observed due to gate force application. Scale bar: 1 m.
