Line Plot from Scientific Research

Solid lines represent the total installed capacities of wind and solar resources under the three baselines, and dashed lines are the future scenarios, described in the text. Columns show the capacity breakdowns by wind and solar technology types under scenario A1. Bands indicate the ranges of the 2035 results under future scenarios.
