Open-circuit voltage of FZJ solar cells before LS (gray symbols) and after LS (red symbols) using the 3LS process or the standard LS process of the FZJ. Each data point corresponds to a (2 x 2) cm2solar cell with four solar cells on one (7.8 x 7.8) cm2wafer. Boxplots display the IQR from the 25th to 75th percentile, with whiskers extending to 1.5 times the IQR.

#Box Plot#Scatter Plot#Open-Circuit Voltage#FZJ Solar Cells#LS Process#3LS Process#Standard LS Process#Solar Cell#Boxplots
