Scatter Plot from Scientific Research

Comparison of the highest peak current densities of monolayer and bilayer graphene RTTs achieved in this study with those of 2D quantum-tunneling NDR devices in the literature (where RTD is resonant tunnling diode). References: MG (monolayer graphene)/BN (boron nitride)/MG 11 , 12 , 23 , BG (bilayer graphene)/BN/BG 14 , 17 , TG (trilayer graphene)/WSe 2 /MoS 2 16 , TG/MoSe 2 /WSe 2 16 , BG/WSe 2 /BG 18 , WSe 2 /BN/WSe 2 19 , 24 , MG/InSe/MG 21 , BP (black phosphorus)/BP/BP (twisted BP homostructure) 22 , MoS 2 /WSe 2 26 , BP/SnSe 2 27 , WS 2 /SnS 2 32 , and WSe 2 /SnSe 2 34 .
