Line Plot from Scientific Research

The solid lines illustrate the sensitivities of the FRF vector magnetometer for the total magnetic field and the two transverse magnetic fields. The dashed line depicts the sensitivity of the magnetometer in scalar mode. The inset highlights the frequency response for b x and b y . The polar angle sensitivities, applicable only to b x and b y , are shown on the right-side y-axis and are calculated by dividing b x and b y by the total static magnetic field, B 0 .
