Box Plot from Scientific Research

Potentiation statistics for a succession of spikes (facilitation or learning process) for over 15 million pulses ( V pot = 2.8 V and V read = 0.75 V). In each cycle, after the 21st facilitation spike, a negative spike ( V reset = -0.7 V) reset the synapse to its initial state ( t pot = 5 s, t read = 10 s and t reset = 1 s; Supplementary Fig. 24 ). Boxes are placed on the median value and represent the 25th and 75th percentiles. Whiskers indicate the 10th and 90th percentiles. Data points per box, 771,000.
