Heatmap from Scientific Research

Heat maps of the tuning capabilities of the firing time for the floating-bulk device at different input spiking frequencies (20 Hz to 200 kHz), amplitudes (3.60–4.50 V) and spike durations (1–10 µs). Low V G2 provides enhanced response at lower frequencies at the cost of slower relaxation times. Black tiles in the maps represent either no firing observed within 10 s or incompatible frequency versus t spike pairs (frequency greater than or equal to t spike –1 )

DOI
