Reversible flattening/wrinkling of 50 nm-thick pDAP membranes subjected to moisture. In (c,d), the top panels show optical microscope images and the bottom panels display differential images taken with respect to the flat membrane state. Square-shaped membrane supporting aperture size in panels (c,d) is 1.5 x 1.5 mm2
#Microscopy#Photo#pDAP Membranes#Moisture#Flattening#Wrinkling#Optical Microscope Images#Aperture Size
