Yearly electricity generation in the European Union from black and brown coal under perfect and myopic foresight. Trajectories in both a and b correspond to newest targets from the Fit for 55 proposal with an active MSR. Note that in both a and b, the 2020 year is fixed to match real 2020 values. Additional data (solar capacity expansion and total electricity mix) on perfect and myopic foresight scenarios can be found in Extended Data Fig. 3.
#Line Plot#Electricity Generation#European Union#Black Coal#Brown Coal#Perfect Foresight#Myopic Foresight#Fit for 55 Proposal#Solar Capacity Expansion#Electricity Mix
