Scatter Plot from Scientific Research

The optimal technology portfolio (using the abbreviations introduced in the model) as a function of sequestration credit and liquid fuel demand for the case when all CO 2 is valued the same. Markers indicate the base case (red) and representative solutions (white) for which plots of the SC configuration are available in Supplementary Figs. 17 – 21.
