Dispersion profile of an LTOI racetrack microresonator with the waveguide cross-section 2 μm × 0.5 μm and a slab 100 nm thick. D 1 /2π = 82.234 GHz, D 2 /2π = 197.88 kHz. L, C, S, E and O telecommunication bands are marked with vertical dashed lines.
#Scatter Plot#Regression Plot#Line Plot#Dispersion Profile#Lithium Tantalate on Insulator#Racetrack Microresonator#Telecommunication Bands
