Line Plot from Scientific Research

Steady-state current density versus voltage (IR corrected) results obtained by galvanostatic measurements at different current densities during bromide electrolysis with (blue symbols) and without (black symbols) borate buffer (0.7 M). For a comparison, results from previous DWE reports are marked by red symbols ( for SRC, for SRE and * for ETAC) and labelled by their respective reference numbers. The electrolyte composition at the beginning of the electrolysis measurements was 1.5 M NaBr with 3.8 mM Na 2 Cr 2 O 7, with and without borate buffer. The electrolyte was heated to 60 C and stirred at 400 r.p.m.
